Page 70: And consoles

Installing and wiring telephones and trunks
70 Installing and Connecting the MDF and Telephones
●
Connecting external alarm indicators and auxiliary power
●
Installing off-premises station wiring
●
Off-premises or out-of-building stations
●
●
Emergency transfer units and associated telephones
●
808A Emergency Transfer Panel and telephone installation examples
●
●
Installing the queue warning indicator
See the Job Aid titled Connector and Cable Diagrams (Pinout Charts) (555-245-773) for
information on pinouts.
Connecting telephones
This section includes the various analog, digital, and IP telephones can be connected to the
media gateway including:
●
Connectable telephones and consoles
●
Connecting a typical telephone
●
●
Connecting an analog station or 2-wire digital station
Connectable telephones and consoles
Table 7: Connectable telephone and consoles
on page 70 lists the telephones and consoles
that can be connected to an Avaya media gateway.
Table 7: Connectable telephone and consoles
Telephone and console models
Type
16xx (Avaya one-X Deskphone Value Edition
Internet Protocol
(IP)
2500/2554
Analog
2402
Digital
1 of 3
