Page 27
Installing Cable Slack Managers
Issue 3 January 2008
27
Figure 9: Cable routing through Cable Slack Manager—example for SCC1 Media Gateway
Figure notes:
1. Top of Media Gateways
2. Cable Clamps
3. Cable Ties (Optional)
4. Power Cord
5. Cable Slack Manager
6. Cable Slack Manager (Cover
Removed)
7. Main Distribution Frame (MDF)
8. Route Cables Along Path Shown
9. Port Cables
3
5
1
2
r758155 CJL 031496
4
