Page 63
Installing and administering the patch cord/jumper
Issue 3 January 2008
63
Figure 29: Example 3-pair labeling to information outlet
Figure notes:
1. Equipment Room
2. Satellite Location
3. Work Location
4. White Row on 110 Terminal Block
5. Purple Row on 110 Terminal Block
6. Blue Row on 110 Terminal Block
7. Central Location for Terminals 1
through 6
8. D-Inside Wire Cut Down to
Connecting Block
9. 258A Adapter
10. Information Outlet
11. Telephone
12. To Port Connector on Media
Gateway (Media Gateway 1,
Position B, Slot 03)
crdf5pr CJL 103096
