Analog Way Pulse - Manual (Page 17)

PHYSICAL
Dimensions: W 482 x D 330 x H 45 mm
19”W x 13”D x 1.8”H.
(Compatible with a Standard 19” rack, Height = 1U).
Weight: 4.3 kg / 9.5 lbs.
ENVIRONMENTAL
Cooling air flow from right side to left side
Maximum ambient operating temperature: < 40°C ( < 104°F)
Operating temperature: 0 to +40°C / +32° to +104°F
Storage temperature: -40 to +70°C / -40° to +158 °F
Operating humidity: 10 to 80% (non condensing)
Input voltage range: 100-240 VAC, 50/60 Hz
Typical consumption: 90 W
CERTIFICATIONS
CE Compliancy test following
- EN 55022: 2006 / A1: 2007,
- EN 55024: 1998 / A1: 2001 / A2: 2003,
- EN 61000-3-2: 2006
- EN 61000-3-3: 1995 / A1: 2001 / A2: 2005,
Safety test following:
- IEC 60950-1: 2005
- UL 60950-1: 2007
- CAN/CSA-C22.2 NO. 60950-1
Power supply: IEC/EN/UL/CSA 60950-1, internal, autoswitchable
Mechanical (in carton): Vibration: IEC60068-2-64
Free fall: IEC60068-2-32, RoHS, WEEE
Environmental specifications
15
• COMMUNICATION PORTS:
REMOTE RS232
Connector: DB 9 female
Level: RS232.
Data Rate: 9600 Bauds, 8 data bits, 1 stop bit, no parity bit,
no flow control for normal. DTR & RTS needed for
upgrade.
Communication specifications
• LAN:
Connector : RJ45
Protocol: TCP (Transmission Control Protocol) or UDP
(User Datagram Protocol).
Ethernet: Base 10/100
