• AUDIO OUTPUT:
Connector: Outputs #1 (Main):
Balanced or unbalanced mono/stereo output
(on 5-pin MCO male connector).
Vo max: Unbalanced = +15dBu (at 300Ω load).
Balanced = +21 dBu (at 600Ω load).
Zo = 600 Ω balanced.
Zo = 300 Ω unbalanced.
G = 0 dB nominal.
• DVI (Digital Video Interface) OUTPUTS:
Connector: Outputs #1 (Main) & #2 (Preview): female DVI-I
(digital pins).
Signal: Digital Visual Interface (DVI)-TMDS single link.
Resolutions:
Balanced connection
Unbalanced connection
14
Format Ratio Available Refresh Rates
HDTV 720p 50Hz 59.94Hz 60Hz
HDTV 1035i 59.94Hz 60Hz
HDTV 1080i 50Hz 59.94Hz 60Hz
HDTV 1080p 23.97Hz 24Hz 25Hz 29.97Hz 30Hz 50Hz 59.94Hz 60Hz
HDTV 1080sF 50Hz 59.94Hz 60Hz
640 x 480 4 : 3 50Hz 60Hz 72Hz 75Hz
800 x 600 4 : 3 50Hz 60Hz 72Hz 75Hz
848 x 480 16 : 9 50Hz 60Hz 72Hz 75Hz
1024 x 768 4 : 3 50Hz 60Hz 72Hz 75Hz
1280 x 720 16 : 9 50Hz 60Hz
1280 x 768 15 : 9 50Hz 60Hz 72Hz 75Hz
1280 x 800 16 : 10 50Hz 60Hz 72Hz 75Hz
1280 x 1024 5 : 4 50Hz 60Hz 72Hz 75Hz
1360 x 768 16 : 9 50Hz 60Hz 72Hz 75Hz
1366 x 768 16 : 9 50Hz 60Hz 72Hz 75Hz
1366 x 800 15 : 9 50Hz 60Hz 72Hz 75Hz
1400 x 1050 4 : 3 50Hz 60Hz 72Hz 75Hz
1440 x 900 16 : 10 50Hz 60Hz 72Hz 75Hz
1600 x 1200 4 : 3 50Hz 60Hz
1680 x 1050 16 : 10 50Hz 60Hz
1920 x 1080 16 : 9 50Hz 60Hz
1920 x 1080HD 16 : 9 50Hz 60Hz
1920 x 1080 B 16 : 9 50Hz 60Hz
1920 x 1080 C 16 : 9 50Hz 60Hz
1920 x 1200 16 : 10 50Hz 60Hz
2048 x 1080 19 : 10 50Hz 60Hz
DVI 1
DVI 2
L
R
L
R
UNBALANCED
LEFT
LEFT
RIGHT
RIGHT
GROUND(S)
Input DVI 1
Input DVI 2
4
L+
L-
R+
R-
BALANCED
L+
R+
L-
R-
GROUND(S)
