I 0568 - 6

4 - CONTROLS AND COMPONENTS

4.1 - Automatic distance + diameter gauge

It allows measurement of the distance from the machine and the wheel diameter at the point of application of the
counterweight. It also allows correct positioning of the counterweights inside rim by using the speciﬁ c function (see

INDICATION OF EXACT CORRECTION WEIGHT POSITION

) which allows reading, on the monitor, the position used for

the measurement inside the rim (for calibration, see the corresponding paragraph).
The gauge can only be used with the counterweight pincers mounted.

4.2 - Keyboard

N.B. - Press the buttons with the ﬁ ngers only: never use the counterweight pincers or other pointed

objects.

- When the beep signal is enabled (see section

ACOUSTIC SIGNAL)

, pressing of any push button

is accompanied by a “beep”.

- The TFT monitor is NOT the TOUCH SCREEN type.

FUNCTION KEYS: they immediately select function indicated on the monitor

Selection of special
functions

Conﬁ rm

Starts measuring cycle

Interrupts machine cycle
