CEMB USA C218 (A) User Manual
Page 4
I 0568 - 4
2
2a
GB
1.4 - Specifi cation
Single phase power supply
115 - 230 V 50-60 Hz
Protection class
IP 54
Max. power consumption
1,1 Kw
Monitor
TFT 15”
Balancing speed
100 r.p.m. for cars - 70 r.p.m. for trucks
Cycle time for wheel
8 to 20 seconds
Balancing accuracy
1 gram for cars / 10 grams for trucks
Position resolution
± 1.4°
Average noise level
< 70 dB(A)
Distance rim - machine
0 - 335 mm (400 mm max. presettable)
Rim width setting range
1.5” to 20” or 40 to 510 mm
Diameter setting range
10 to 30” or 265 to 765 mm
Max. wheel weight
250 kg
Max. wheel diameter
1300 mm
Min/max. compressed air pressure
8 to 10 kg/cm
2
approx. 0.8 to 1MPa
approx. 8 to 10 BAR
approx. 115 to 145 PSI
2 - HANDLING AND LIFTING
To lift the machine, lever only on the base where the 3 support points are located. Never, under any circum-
stance, apply force to other points such as the spindle, head, or accessory shelf.
Check that the balancing machine touches the fl oor at the three support points. The machine does not require
anchoring to the fl oor for correct operation for wheels up to 160 kg. in weight.
Alternative options:
Front wheel translation KIT
Ground
securing
plate
KIT
