CASTLE, INC AT‐8 OWNERS MANUAL V2.1 Page 6 of 30
2 ¼-20 x 3-1/2” Draw Bolt F14312
4 ¼ USS Washer F01411
4 5/16-18 T Nut F51698
4 5/16-18 x 5/8 HHCS F51638
2 ¼-20 Hex Nuts F01423
2 ¼-20 x 5/8 HHCS F14585
30 #10 x 2-1/2” Phillips Pan Head Sheet Metal
Screw (Worktop Installation) F10212
4 5/16 Small Aluminum Spacer (Fence
Installation) N00346
8 5/16 Large Aluminum Spacer (Fence
Installation) N00345
12
2
¼-20 Kep Nut (Fence Installation)
(Arm Stop Bolts)
F01422
12 ¼-20 X 1-3/4 FHCS (Fence Installation) F44134
25 5/16-18 Hex Nuts (Frame Assembly) F51628
25 5/16-18 X 7/8 HHCS (Frame Assembly) F51878
Part Qty Part Description Part #
CASTLE AT-8 ASSEMBLY TABLE HARDWARE PACK
2 ¼-20 x 3-1/2” Draw Bolt F14312
4 ¼ USS Washer F01411
4 5/16-18 T Nut F51698
4 5/16-18 x 5/8 HHCS F51638
2 ¼-20 Hex Nuts F01423
2 ¼-20 x 5/8 HHCS F14585
30 #10 x 2-1/2” Phillips Pan Head Sheet Metal
Screw (Worktop Installation) F10212
4 5/16 Small Aluminum Spacer (Fence
Installation) N00346
8 5/16 Large Aluminum Spacer (Fence
Installation) N00345
12
2
¼-20 Kep Nut (Fence Installation)
(Arm Stop Bolts)
F01422
12 ¼-20 X 1-3/4 FHCS (Fence Installation) F44134
25 5/16-18 Hex Nuts (Frame Assembly) F51628
25 5/16-18 X 7/8 HHCS (Frame Assembly) F51878
Part Qty Part Description Part #
CASTLE AT-8 ASSEMBLY TABLE HARDWARE PACK
