CASTLE, INC AT‐8 OWNERS MANUAL V2.1 Page 18 of 30
4 Operating Instructions
Warning: Always wear eye protection when operating pneumatic equipment.
4.1 Cylinder Actuation
To operate the clamp cylinder locate the black lever with the rubber stopper. Moving this lever
back and forth will clamp and release the cylinder.
Your Assembly Table beam arm is fitted with (5) ports for air fittings and can accommodate an
optional fifth clamp cylinder.
