CASTLE, INC AT‐8 OWNERS MANUAL V2.1 Page 12 of 30
3.2 Fence Installation
1. Attach the fences using the ¼-20 Flat Head bolts [F44134] , aluminum spacers [N00345
and N00346] and the ¼-20 Kep Nuts [F01422] . The side fence uses the small spacers
and the bottom fence uses the larger spacers.
Caution: When fastening the fences be sure to only tighten one bolt on each
fence at the bottom left corner of the frame. You will tighten the rest later.
