TG44D

Section C: Advanced Troubleshooting

(CONT’D)

Troubleshooting

Shut down vehicle and restart engine. If alternator

functions normally after restart, a “no output condition”

was normal response of voltage regulator to “high volt-

age” condition. Inspect condition of electrical system,

including loose battery cables, both positive and

negative. If battery disconnects from system, it could

cause “high voltage” condition in electrical system,

causing OVCO circuit to trip.
If you have reset alternator once, and electrical system

returns to normal charge voltage condition, there may

have been a one time, high voltage spike, causing OVCO

circuit to trip.
If OVCO circuit repeats cutout a second time in short

succession and shuts off alternator relay circuit, try

third restart. If OVCO circuit repeats cutout, go to Chart

3, page 8.

N3044 and N3261 Regulators

DESCRIPTION AND OPERATION
N3044
and N3261 regulators are mounted directly to

the outside of the alternator.
Main diagnostic feature of

N3261 regulator consists of a

tricolored (green, amber, red) LED located on the top of

the regulator. The LED works like a voltmeter, measur-

ing charging voltage. See Table 2 for diagnostic features

and LED explanations.
N3044 and N3261 regulators have OVCO (overvoltage

cutout) and will trip at vehicle electrical system voltage

above 32 volts that exists longer than 3 seconds. OVCO

feature detects high voltage and reacts by signaling relay

in F+ alternator circuit to open. This turns off alterna-

tor (LED on N3261 is solid RED). OVCO circuit is reset

when engine is restarted. Regulator then regains control

of alternator output voltage.

LED COLOR

STATUS

TABLE 2 – N3261 Regulator Diagnostics

Alternator and regulator operating normally.

GREEN

Flashing

System voltage is lower than setpoint—electrical
load exceeds alternator rating at present rotor
speed.

ACTION

No action required.

AMBER

Flashing

System voltage higher than setpoint.

If flashing more than 3 seconds, OVCO will trip,
disabling charging system. LED will flash RED.
Overvoltage condition. System diagnosis
required. Go to Chart 3, page 8.

RED

Flashing

CLEAR

LED off

Check for system voltage at IGN terminal on regu-
lator. If OK, replace regulator. If not OK, check
vehicle wiring and ignition circuit.

Energize circuit fault.

When loads decrease or speed increases, LED
should be flashing GREEN. If not, check drive
belt and charging system connections.

Solid

OVCO tripped.
