Page 3

TG54B

Basic Troubleshooting

1.

Inspect charging system components for

damage

Check connections at B– cable, B+ cable, and
alternator-to-regulator harness. Repair or

replace any damaged component before trouble-
shooting.

2.

Inspect all vehicle battery connections

Connections must be clean and tight.

3.

Determine battery voltages and states of

charge

If batteries are discharged, recharge or replace

batteries as necessary. Electrical system cannot
be properly tested unless batteries are charged

95% or higher. In addition, open circuit voltages
must be within ± 0.2 V.

4.

Connect meters to alternator

Connect red lead of DMM to alternator B+

terminal and black lead to alternator B– termi-

nal. Clamp inductive ammeter on B+ cable.

5.

Operate vehicle

Observe charge voltage.

If charge voltage is above

16 volts, immediately shut

down system. Electrical

system damage may occur

if charging system is allowed

to operate at high voltage.

Go to Table 1 at left.

If voltage is at or below regulator setpoint, let

charging system operate for several minutes to
normalize operating temperature.

6.

Observe charge volts and amps

Charge voltage should increase and charge amps

should decrease. If charge voltage does not
increase within ten minutes, continue to next

step.

7.

Batteries are considered fully charged if charge

voltage is at regulator setpoint and charge amps

remain at lowest value for 10 minutes.

8.

If charging system is not performing properly,

go to Chart 1, page 4.

SYMPTOM

ACTION

TABLE 1 – System Conditions

Low Voltage Output

High Voltage Output

No Voltage Output

Preliminary Check-out

Check symptoms in Table 1 and correct if necessary.

Identification Record

List the following for proper troubleshooting:

Alternator model number ______________________

Regulator model number _____________________

Setpoints listed on regulator ___________________

Section B: Basic Troubleshooting

CAUTION

Check: loose drive belt; low bat-

tery state of charge.

Check: current load on system

is greater than alternator

can produce.

Check: defective wiring or poor

ground path; low regulator

setpoint.

Check: defective alternator or

regulator.

Check: wrong regulator.
Check: high regulator setpoint.
Check: defective regulator.
Check: alternator.
Check: broken drive belt.
Check: battery voltage at alter-

nator output terminal.

Check: defective alternator or

regulator.

Check: lost residual magnetism

in self-energizing alternator.

A2-155 regulator: Chart 1

Tools and Equipment for Job

• Digital Multimeter (DMM)

• Ammeter (digital, inductive)

• Jumper wires
