C.E. Niehoff & Co. N1245-1_N1248-3 Alternator/N3043 Regulator Installation - Manual (Page 2)

II0105B
Page 2 of 2
Figure 1b – 28 V B+ Terminal Stacking Order
Lock washer
Ground Terminal Bolt,
5/16-18 UNC-2A;
torque to 9 Nm / 80 lb. in.
Vehicle
ground lead
Figure 1c – Ground Terminal Stacking Order
Terminal from vehicle output leads
Washer
Lock
washer








Bolt, 3/8-16;
torque to 15 Nm / 11 lb.ft.

 Washer
If you have questions about your alternator or any of these instructions, or if you need to locate a Factory Authorized Service Dealer, please contact us at:
C. E. Niehoff & Co.• 2021 Lee Street • Evanston, IL 60202 USA
TEL: 800.643.4633 USA and Canada • TEL: 847.866.6030 outside USA and Canada • FAX: 847.492.1242
E-mail us at [email protected]
