Dual circuit cooking Areas
Depending on the model, one or two areas may have
a second circuit. There are two types:
ROUND – comprising a central disk and external
crown,
OVAL – comprising a lateraldisk and half-crown.
One disk zone or both (disco-crown/ half-crown) can
be switched on.
Switching on a twin circuit zone
The twin circuit zone must already be activated with
relative decimal point
1 illuminated.
 Select the required setting (1 – 9) 2.
 Press the twin circuit key 3 to switch it on.
The LED
4 for the selected zone will light up; the
second circuit will be activated together with the first.
Switching off the second Circuit
The twin circuit zone must already be activated with
relative decimal point
1 illuminated.
 Press the twin circuit key 3.
The LED
4 for the selected zone will go out to
indicate deactivation of the second circuit.
3 2
1 4
