PA Industries MINI Servo Roll Feed SRF-105M through SRF-320 User Manual
Page 6

Form 1145 Mini Installation Form and Operation Manual 02/02/2006
6
4. PROGRAMMING THE “MINI”
IMPORTANT!
Before turning the system on for the first time, verify that the main input voltage is correct (115 VAC single phase)
and inspect all connections for tightness, shorts, etc.
Plug the 115 VAC plug into a clean 10 Amp supply (15 Amp for SRF-320 model. Press the amber ‘POWER ON’
push button. The button will illuminate and the data input display will be visible. If pressing the ‘POWER ON’ push
button has no effect, then check the ‘TWIST-TO-UNLOCK’ Emergency Stop button for the ‘UP’ or ‘RELEASED’
position.
Start up screen is displayed for about 5 seconds.
P / A I n d u s t r i e s I n c
M I N I
S e r v o R o l l
F e e d
V
2 . 1 C o p y r i g h t 2 0 0 4
Provided no fault is present, the following screens will appear sequentially:
C h e c k i n g
s e r v o d r i v e
N o f a u l t s f o u n d !
C o m m u n i c a t i o n s
w i t h s e r v o d r i v e
e s t a b l i s h e d
In case of a fault condition present in the servo drive, the following flashing screen will display all present faults by
their numbers. Fault numbers and their descriptions are listed in the fault table on page 13 of this manual.
F a u l t c o d e : 3 0
S
e e f a u l t c o d e t a b l e
Any fault problem must be solved before further operating.
Normally, there are no faults and the keypad reads values of Length, Speed and Accel, stored in the servo drive.
G e t t i n g L e n g t h
