Form 1145 Mini Installation Form and Operation Manual 02/02/2006

21

7. MAINTENANCE

The Mini Servo Roll Feed needs very little maintenance to keep the system operating at its optimum performance.

This precision equipment must be kept as clean as possible. This is especially important if large amounts of

air suspended oil mists in combination with “dirty metals” are used. The resulting abrasive dust can attach itself to the
feed rolls and other surfaces, leading to premature wear on many parts.

The roll release system requires a clean, dry air supply.

Some bearings used on the feeder are fully sealed and maintenance-free roller ball bearings. The exceptions

are provided with standard “zerk” type grease fittings. They should be lubricated with a good grade of high pressure
bearing grease. The frequency of lubrication will depend on the overall usage of the system. A small “shot” once a
day is a good starting point. The cluster gear set should be coated with a small amount of open gear grease.

The main drive belt should be checked periodically for tightness. It can be adjusted by loosening the three

fasteners on the motor adjuster plate, applying downward pressure on the plate, and retightening. ERRATIC MOTOR
BEHAVIOR WILL BE EXPERIENCED IF THE DRIVE BELT IS LOOSE!

All fasteners should be checked for tightness at regular intervals. The electrical system also requires very little

maintenance. Keep the enclosure clean and replace any burned indicator bulbs. Do not expose the electrical enclosure
to constant high temperatures. Possible system failure could result.

The Feeder’s electrical enclosure door is sealed to prevent oil and contaminants from entering inside.

However, small gaps can be found around some sealing surfaces and faceplates. It is a good idea, therefore, to keep the
console free of stamping oils and fluids, which could "seep into" the enclosure. Most often these oils are carried by the
operator’s hands or by air mist lubrication etc.

All of the above guidelines should be added to your existing pressroom Preventive Maintenance

(PM) Program.

8. ROLL FEED PARTS LIST & DIAGRAM


List of parts that are common for 105M through 320M models

Item Q-ty

Part

#

Description

Item Q-ty

Description

Part

#

01

01

R-SRF-MINI-01

Left housing bearing

35

01

Hex head cap screw

DIN-912-M14x120

02

01

R-SRF-MINI-02

Lower front dust shield

36

01

Nut

DIN-934xM14

03

01

R-SRF-MINI-03

Right housing bearing

37

01

Adjustment tab

R-SRF-MINI-37

04

01

R-SRF-MINI-04

Lower rear dust shield

39

02

Key

18144

02 02 R-SRF-MINI-06

Spring

43 02 Manual

release

lever R-SRF-MINI-43

07 02 R-SRF-MINI-07

Spring

housing

45 02

Needle

bearing

R-SRF-MINI-45

08 02 R-SRF-MINI-08

Adjust

screw

46 04

Thrust

race

R-SRF-MINI-46

09 02 DIN-916-M12x12

Set

screw

47 01

Key

15104-24

10

01

DIN-7991-M5x16

Flat head screw

48

02

Ball point screw

R-SRF-MINI-48

11 04 R-SRF-MINI-11

Bearing

49 02

Cam

follower

R-SRF-MINI-49

12 01 R-SRF-MINI-12

Lower

gear

51 02

Set

screw

13 01

15104-22

Key

52 02

Needle

bearing

R-SRF-MINI-52

14 01

15104-23

Key

53 02 Lower

roll

spacer R-SRF-MINI-53

16

01

R-SRF-MINI-16

Upper gear

54

01

Hex head cap screw

DIN-912-M10x60

21

01

R-SRF-MINI-21

Upper roll spacer

55

03

Roll release bearing

R-SRF-MINI-55

22

01

R-SRF-MINI-22

Upper roll fixed plate

56

01

Release bearing spacer

R-SRF-MINI-56

23 02 R-SRF-MINI-23 Cascade

bracket 57 01

Mechanical release lever

R-SRF-MINI-57

26 04 R-SRF-MINI-26

Dry

bearing

58 01

Washer

DIN-1278-M10

27 02 R-SRF-MINI-27 Adjustable

hand

lever 59 01

Nut

DIN-934-M10

28

01

R-SRF-MINI-28

Guide roll spacer

60

01

Upper front dust shield

R-SRF-MINI-60

29 01 R-SRF-MINI-29

Bearing

61 01 Upper

rear

dust

shield R-SRF-MINI-61

30 02 DIN-934-M10

Hex

nut

62 01

Key

15104-25

34 01 R-SRF-MINI-34

Motor

bracket
