62 Appendices
Appendix N: Connector
SDL Mating Connector
37 way Deutsch: AS6-14-35SN
Wire
Wire to suit connector: 22# Tefzel, Mil Spec : M22759/16-22
Crimp Tool
Crimp Tool : M22520/2-01
Positioner for Crimp Tool : M22520/2-07
• Note that the Crimp Contacts are type 22D (needed to set the crimp tool
correctly)
Wire Stripping Tool
The following tool is recommended
Ideal Industries 45-2133 stripping tool with LB1195 wire stop.
Heatshrink Boots
Straight: Raychem 202K142, Hellerman 155-42-G
Right Angle: Raychem 222K142, Hellerman : 1155-4-G
