58 Appendices
Appendix K: Typical Wiring (with BR2)
The wiring below shows typical wiring for BR2 on CAN plus USB for PC
connection.
For more detail on the CAN Bus wiring refer to Appendix H: CAN Wiring.
For more details on USB wiring refer to Appendix J: USB Wiring.
1
Ground
BR2
0V
SDL
37
2
SwOut
3
Power
8V
13
4
CAN-LO CAN-LO
35
5
CAN-HI CAN-HI
36
CAN-LO
CAN-HI
CAN Device
eg M800
ECU
100
R
100
R
See the CAN Bus
Wiring Specification
for more detail
Any Other
CAN Device
10
24
USB-VCC
USB-DM
USB-DP
USB-GND
25
9
Red
White
Green
Black
Shield
USB B
Type
Socket
See the USB
Wiring
Specification
for more detail
