MoTeC SDL - Manual (Page 44)

42 Appendices
Appendices
Appendix A: General Specifications
Physical
Case Size SDL: 180.5 x 91.5 x 18.0 mm (7.1 x 3.6 x 0.7 inches)
Weight 385 grams (0.85 lb)
Power Supply
Operating Voltage: 7 to 22 Volts DC
Operating Current: 0.15 Amps Typical (excluding sensor currents)
Reverse Battery Protection
Battery Transient Protection
Operating Temperature
Internal Temperature Range -10 to 80
°C
Ambient Temperature Range -10 to 70
°C typical
Sensor Supply Current
5V Sensor Supply : 0.2 Amps Max
8V Sensor Supply : 0.3 Amps Max
Internal Sensors
G Force Lateral
G Force Vertical
Battery Voltage
Dash Temperature
