ADR Functionality User Manual Configuration
Communications Tab
Figure 5 – Device Configuration – Example Communications Tab
The functions of the parameters on the Communications tab are as follows.
CAN Transmit (base)
Address This is the first of the two sequential addresses used for by the ADR for
transmitting status messages.
CAN Receive (base) Address This is the first of the five sequential addresses used by the ADR for receiving
CAN channels.
Further Information:
See the
CAN Bus section on page 19 for more detailed information on CAN messaging.
GPS / Enable Receive Used to enable or disable GPS reception. Disabling the GPS will prevent the
GPS diagnostic bits (in the CAN status messages) from being set.
GPS baud rate This can be set to 9600, 19200, 38400, 57600 or 115200.
Further Information:
See the
GPS and Timekeeping section on page 17 for more detailed information on GPS communications.
