Faults
Faults
Various fault conditions are monitored by the ADR. The presence of a fault is indicated by the Status LED, and the fault
information is transmitted in the CAN status messages.
The following checks are performed.
Fault check
Description
External LED open
circuit fault
The external LED open circuit test is performed only during the power ON lamp test (on
application of power to an unpowered ADR).
See the
for more detail on the lamp test.
If an external LED is not used with the ADR then the external LED output should be disabled
in the configuration; see the
.
Calibration and
configuration faults
Whenever the ADR is restarted, the integrity of the stored calibration and configuration are
checked.
Internal faults
Whenever the ADR is restarted, the internal accelerometer, flash memory and oscillator
tests are performed.
Internal voltage rail
faults
The internal voltage rails are constantly monitored for correct voltage.
