ADR Functionality User Manual Specifications
Specifications
Communications
• CAN
• RS232 (for GPS receive)
• USB (for future use)
Connectors
• 1 x 11 pin double density size 8 Autosport connector
• Matching connector: MoTeC #68109 - Autosport double density female (red)
Physical construction and dimensions
• Case size (mm): 73.5 x 45 x 27
• Case material: anodized aluminum
• Internal components encapsulated
• Weight (gram): 110
Power
• Power supply (vehicle battery): 6 – 30V
• Current: 1A peak, 200mA steady state
• USB power when connected to PC (if no other power source)
• Backup power (internal super capacitor): 30 seconds of logging and 10 minutes of LED operation when power
supply lost (no battery required)
• Backup power recharge: under one minute after connection to a power source
Operational
• G force recording of lateral, longitudinal and vertical channels at 1000Hz
• Recording of up to 20 CAN channels at 100Hz
• G force range: -150G to +150G
• G force channel resolution: 0.1G
• GPS data recorded:
o
Date and time
o
Latitude and Longitude
• Pre-event (accident) recording duration: 2 seconds
• Event duration: 30 seconds
• Event capacity storage: 10 events
• Data output format: CSV
