ADR Functionality User Manual
Configuration
Device Configuration Buttons
The Load, Save, Send and Close buttons are used to perform the following functions:
Load
Load an existing configuration to the ADR Manager from disk.
Save
Save the current configuration in the ADR Manager. This does not apply the configuration to the
ADR.
Send
Apply the configuration to the ADR. The ADR configuration remains unchanged until another
configuration is sent.
Close
Closes the Device Configuration window.
General Tab
See Figure 3, the function of the parameters on the General tab is as follows.
Identity/Name
Optional name for the ADR.
Mounting Orientation
The orientation of the installed ADR must be specified. This allows the
accelerometer readings to be correctly aligned to the vehicle. See the
section on page
for more detail.
Supercapacitor
Recharge/Recharge Rate
The rate determines how fast the super capacitor is charged. The maximum rate
(100%) is recommended for most applications.
The higher the charge rate, the quicker the supercapacitor reaches full charge.
See the
for more detail.
