Section 18: Appendix B: Specifications
Operating Temperature Range
-40°C to +55°C
Power Supply Specifications
Supply voltage: 48Vdc +/-10%
Reverse polarity protected
Power requirement; 120W nominal at 48V with white strobe in day mode,
20W with white strobe in night mode, at 60FPM and 550ft of 18AWG cable
Red beacon power requirement nominally 45W when steady burning
Maximum flash rate 60 FPM
Dimensions - 12 x 12.75
Weight - 10 Pounds
Light Engine
Weight
28 Pounds
Height
(See Flash Head Dimensions on previous page)
7.06 Inches
Diameter
(See Flash Head Dimensions on previous page)
17.00 Inches
Bolt Hold Down Pattern – Standard Pattern provided
(See Base Bottom View)
