DIAGRAM SHOWING HOW TO SYNCHRONIZE FLASH RATES
Day/Night contact
Connect to Common for Night mode
Dim 0
Connect Dim 0 to Common to reduce light output to
30% of maximum
Dim 1
Connect Dim 1 to Common to reduce light output to
10% of maximum
Two uncommitted solid-state relay outputs are provided to indicate a fault with
the Red or White Beacon;
Red Fault A
Red Fault B
White Fault A
White Fault B
Each solid state relay is rated for up to 600V/40mA max, 20mA continuous. The
relays can either be configured to close or open when there is a fault condition,
or pulse (fail safe, at a rate of 1 Hz with a duty cycle of 50%) when all is OK by
means of the Configuration Options switch.
Sync Out
Sync In
Sync In
To Sync In of other synchronized strobes
Master Strobe
Slave Strobe
