Section 8: Configuration Option Switches
Switch
1
Selects night mode color
2
N/A
3
Selects whether fault relays pulse while system is OK
4
Selects whether fault relays open or close on fault
CONFIGURATION SWITCH SETTINGS (on Microcontroller Board)
ON
OFF
1.
White at night
Red at night
2.
Reserved
Must be set to OFF
3.
Relays pulse while system is OK
Relays do not pulse
4.
Relays open on fault
Relays close on fault
Section 9: Configuration Via Serial Port
Certain parameters may be configured via a serial port on the microcontroller
board. This allows different pulse times and duty cycles to be set up, as well as
allowing for additional monitoring capabilities. See Appendix A for more
information about the connection and protocol.
1 2 3 4
ON
