Bray 6A Series Quick Start - Manual (Page 2)

Mounting and Set-up
Step 1: Place the mounting bracket on the rear
side of the positioner. Tighten the mounting
bolts and lock washers.
Step 2: Position the output shaft of the
positioner so that the flat portion is facing
upwards.
Step 3: Insert the coupler over the output
shaft. Be sure to align the coupler’s setscrew
with the flat of the shaft, tighten the set screw.
Step 4: Place the indicator on the base of the
coupler.
