Pneumatic Actuator Data (Imperial)
Actuator Speeds (Seconds)
Size
48
63
83
93
119
128
160
210
255
90° Travel
1/4
1/4
1/4
1/4
1/2
1/2
1
2
2 3/4
Note: Times shown are in seconds at 80 PSIG supply pressure with 6ft. tubing having an internal diameter of approximately 1/4”. Bray
S92/93 actuation times are very dependent on the flow capacity of their air supply. The use of smaller port solenoids, solenoid
manifolds, smaller I.D. air supply tubing and/or extended lengths of tubing can significantly reduce the actuation time and/or
initial response to the command signal.
Actuator Weights (lbs)
Size
48
63
83
93
119
128
160
210
255
Double Acting
2.0
3.3
6.3
8.5
18.0
21.5
39.0
78.0
143.5
Spring Return
2.3
3.9
8.1
10.9
23.4
28.1
53.4
111.0
214.9
Weights are in lbs. Spring Return unit weights are with full set of springs on each piston.
Actuator Volumes (in
3
)
Size
48
63
83
93
119
128
160
210
255
Counter-Clockwise
5.7
9.6
24.8
39.0
81.0
106.5
187.5
360.0
750.0
Clockwise
4.8
13.4
32.6
50.1
102.7
140.6
259.6
450.0
900.0
Counter-clockwise: Air volume in cubic inches required to push pistons apart, full travel.
Clockwise: Air volume in cubic inches required to push pistons together, full travel.
Pneumatic Actuator Data (Metric)
Actuator Speeds (Seconds)
Size
48
63
83
93
119
128
160
210
255
90° Travel
1/4
1/4
1/4
1/4
1/2
1/2
1
2
2 3/4
Note: Times shown are in seconds at 5.5 bar supply pressure with 1.8 meter tubing having an internal diameter of approximately (6.35
mm). Bray S92/93 actuation times are very dependent on the flow capacity of their air supply. The use of smaller port solenoids,
solenoid manifolds, smaller I.D. air supply tubing and/or extended lengths of tubing can significantly reduce the actuation time
and/or initial response to the command signal.
Actuator Weights (kg)
Size
48
63
83
93
119
128
160
210
255
Double Acting
0.9
1.5
2.9
3.9
8.2
9.8
17.7
35.4
65.1
Spring Return
1.0
1.8
3.7
4.9
10.6
12.7
24.2
50.3
115.7
Weights are in kg Spring Return unit weights are with full set of springs on each piston.
Actuator Volumes (cm
3
)
Size
48
63
83
93
119
128
160
210
255
Counter-Clockwise
93.4
157.3
406.4
638.6
1327.5
1744.5
3072.6
5899.3
12290.3
Clockwise
78.7
219.6
534.2
820.5
1683.1
2303.3
4254.1
7374.2
14748.4
Counter-clockwise: Air volume in cubic millimeters required to push pistons apart, full travel.
Clockwise: Air volume in cubic millimeters required to push pistons together, full travel.
