Bray Pneumatic Actuators & Accessories - Manual (Page 2)

All statements, technical information, and recommendations in this bulletin are for
general use only. Consult Bray representatives or factory for the specific requirements
and material selection for your intended application. The right to change or modify
product design or product without prior notice is reserved.
Bray Pneumatic Actuators &
Accessories
Technical Manual - Table of Contents
Topic Page(s)
Actuator
Installation Notes ............................................................. 3
Mounting Codes ............................................................... 3
Pneumatic Actuator Data.................................................. 4
Series 92 Torque Data ....................................................... 5
Series 93 Torque Data (Imperial) ....................................... 6
Series 93 Torque Data (Metric) ......................................... 7
Proximity Switch
Series 52 Proximity Switch Models ................................... 8
Series 52 Proximity Switch and Display Dimensions ......... 9
Series 52 Specifications ................................................... 10
Series 50 Switch Options ................................................. 11
Positioner
Series 64 Positioner ......................................................... 12
Operators
Series 05 Declutchable Gear Operator ............................. 13
