Connecting the Cables
Connecting the Ethernet Cables
Connecting to the Network
1. Connect one end of your Ethernet LAN cable to an available port of your
Ethernet Hub
.
2. Connect the other end to the LAN port at the back of the product.
Connecting the Printer Cable
1.
Connect one end of the printer cable (USB cable) to the printer.
2.
Connect the other end to the COPY port at the rear of the product.
LAN Port
COPY Port
