Data Sheet
Acquisition System
Characteristic DPO70404B
DSA70404B
MSO70404
DPO70604B
DSA70604B
MSO70604
DPO70804B
DSA70804B
MSO70804
DPO71254B
DSA71254B
MSO71254
DPO71604B
DSA71604B
MSO71604
DPO72004B
DSA72004B
MSO72004
Sample Rates
Real-time Mode 1, 2, 3,
or 4 Channel (Max)
25 GS/s 50 GS/s
ET/IT Mode (Max) 5 TS/s 10 TS/s
Maximum Record Length per Channel
With Standard
Configuration
10M on all four channels (DPO70000B and MSO70000 Series)
20M on all four channels (DSA70000B Series only)
With Record Length
Option 2XL
20M on all four channels (DPO70000B and MSO70000 Series)
With Record Length
Option 5XL
50M on all four channels
With Record Length
Option 10XL
125M on all four channels
With Record Length
Option 20XL
N/A 250M on all four channels
Maximum Duration at Highest Real-Time Resolution
Timing Resolution 40 ps (25 GS/s) 20 ps (50 GS/s)
Max Duration with
Standard Memory
0.4 ms DPO70000B and MSO70000 Series; 0.8 ms
for DSA70000B Series
0.2 ms DPO70000B and MSO70000 Series; 0.4 ms
for DSA70000B Series
Max Duration with
Option 2XL
0.8 ms (DPO70000B and MSO70000 Series) 0.4 ms (DPO70000B and MSO70000 Series)
Max Duration with
Option 5XL
2.0 ms 1.0 ms
Max Duration with
Option 10XL
5.0 ms 2.5 ms
Max Duration with
Option 20XL
N/A 5.0 ms
Logic Channels (MSO70000 only)
Characteristic MSO70404 MSO70604 MSO70804 MSO71254 MSO71604 MSO72004
Sample Rate – All
Channels (Max)
12.5 GS/s
Timing Resolution 80 ps
Displayed
Channel-to-Channel
Timing Uncertainty
<160 ps
Maximum Record
Length per Channel
125M on all channels (Option 10XL) 250M on all channels (Option 20XL)
Minimum Detectable
Pulse Width
<400 ps
Maximum Number of
Buses
16
Number of Channels
per Bus
Up to 24 (16 logic, 4 analog, 4 math)
16 www.tektronix.com
