Page 16

background image

Block diagram of digital signal processing

Display and LAN

IF spectrum

Digital audio
via LAN

I/Q data
via LAN

Clear/write

Analog audio

3 IF

Demodulation

bandwidths

100 Hz to 5 MHz

DDC

IF spectrum

1 kHz to 20 MHz

DDC

Display and LAN

4096 points

16 bit

HF direct

IF panorama
path

Demodulation
path

Video spectrum

Video/IF
analog output

16 bit

AGC

MGC

ABS

value

Demod

FFT

16 bit

A

D

Digital up-

converter

A

D

ITU

measurement

Average

Min.

hold

Max.

hold

Fast

Peak

RMS

Average

Level

measurement

A

D

Lowpass filter

16

IF spectrum

FFT calculation of the IF spectrum is performed in a num­
ber of steps. These are described below in simplified form
for an IF bandwidth of 20 MHz ( BW

IF spectrum

= 20 MHz),

which yields high spectral display.

Due to the finite edge steepness of the IF filter, the sam­
pling rate f

S

must be larger than the selected IF bandwidth

BW

IF spectrum

. The quotient of the sampling rate and the

IF bandwidth is thus a value > 1 and is a measure of the
edge steepness of the IF filter. This relationship is ex­
pressed by the following two formulas (for the AUTO
setting):


or

f

S

= BW

IF spectrum

× const

The value of the constant is dependent on the selected
IF bandwidth, i.e. it may vary as a function of the IF
bandwidth.

Analog signals are reconverted from the I/Q data by a
16 bit D/A converter; they are then available as analog
IF signals or analog video data.

High receiver sensitivity, high signal resolution

The R&S®EB500 features an IF bandwidth of up to
20 MHz. This allows even very short signal pulses to be
captured since the receiver displays the wide bandwidth
of 20 MHz in a single spectrum around the set center fre­
quency without any scanning being required.

Using the AUTO setting, the widest IF bandwidth of
20 MHz yields the widest spectral display; the narrow­
est IF bandwidth of 1 kHz yields maximum sensitivity and
resolution.

The receiver’s IF spectrum is digitally calculated using Fast
Fourier Transform (FFT). The use of FFT computation at the
IF offers a major advantage: The receiver sensitivity and
signal resolution are clearly superior to those of a conven­
tional analog receiver at the same spectral display width.

const

BW

IF spectrum

f

s

=
