Rohde & Schwarz R&S®EB500 Monitoring Receiver 11
Specifications in brief of the R&S®ESMD
Frequency range
Base unit
20 MHz to 3.6 GHz
HF option 9 kHz to 32 MHz
SHF option 3.6 GHz to 26.5 GHz
Linearity, third-order intercept, inband
9 kHz to 32 MHz
typ. 35 dBm (low distortion mode)
20 MHz to 3.6 GHz typ. 25 dBm (low distortion mode)
3.6 GHz to 26.5 GHz typ. 17 dB (attenuation > 0 dB)
Noise figure
400 kHz to 32 MHz
typ. 12 dB (normal mode)
20 MHz to 3.6 GHz typ. 9 dB (low noise mode)
3.6 GHz to 26.5 GHz typ. 16 dB
IF bandwidth
Spectral path
1 kHz to 20 MHz (80 MHz)
Demodulation path 100 Hz to 20 MHz (80 MHz for I/Q)
Data interface 1 Gbit LAN (Ethernet 1000BaseT)
Parallel demodulation of multiple narrowband
signals and simultaneous broadband spectrum
scanning
Multiple R&S®EB500 devices can be combined with a fast
and powerful search receiver (e.g. the R&S®ESMD) and
operated as a system. The R&S®EB500 devices demodu­
late signals and produce audio or I/Q data streams, while
the R&S®ESMD quickly searches for other signals with an
extremely high level of sensitivity. A separate R&S®EB500
is required for each signal that is to be processed in
parallel.
The handover of a signal from the R&S®ESMD to an
R&S®EB500 is carried out from the user workstation run­
ning with R&S®RAMON system software. The major
advantage of this system configuration is that the fast
signal search across a wide frequency scenario and the
narrowband production of multiple audio or I/Q data
streams occur simultaneously. This allows the user to
achieve optimum results in a minimum of time.
Handoff receiver in
networked systems
Multiple R&S®EB500 devices can be operated together with
an R&S®ESMD and operated as a system.
