9
JD72OC-SerieS Cable anD antenna analyzerS
Specifications continued
Optional RF power meter (Option 001)
Display range –80 to +120 dBm
Offset range 0 to 60 dB
Resolution 0.01 dB or 0.1 x W x = m, u, p
RF power sensors
Directional power sensors JD731B JD733A
Frequency range 300 MHz to 3.8 GHz 150 MHz to 3.5 GHz
Dynamic range 0.15 to 150 W (Forward avg) 0.1 to 50 W (Forward avg)
4 to 400 W (Peak) 0.1 to 50 W (Peak)
Measurement type Forward/reverse average power, forward peak power, VSWR
Accuracy ±(4 % of reading + 0.05 W) 1,2
Connector type Type-N(f) on both ends
Connectivity USB
Terminating power sensors JD732A JD734A JD736A
Frequency range 20 MHz to 3.8 GHz
Dynamic range –30 to +20 dBm
Measurement type Average Peak Average and Peak
Accuracy ±7% 1
Connector type Type-N(m)
Connectivity USB
Terminating power sensors JD72450551 JD72450552
Frequency range 40 MHz to 3 GHz 40 MHz to 4 GHz
Dynamic range –30 to 0 dBm –40 to 0 dBm
Measurement type Average Peak
Accuracy ±10% 1
Connector type Type-N(m)
Connectivity Serial
1. CW condition at 25°C ±10°C
2. Forward power
Optional optical power meter (Option 002)
Display range –100 to +100 dBm
Offset range 0 to 60 dB
Resolution 0.01 dB or 0.1 x W x = m, u, p
Optical power sensors
Optical power sensors MP-60* MP-80*
Wavelength range 780 to 1650 nm
Max permitted input level +10 dBm +23 dBm
Accuracy ±5%
Connector input Universal 2.5 and 1.25 nm connector
Connectivity USB
*The MP-60 and MP-80 data sheets provide detailed specifications.
