JD72OC-SerieS Cable anD antenna analyzerS
Ordering information
Basic model
JD723C Cable and Antenna Analyzer (100 MHz to 2.7 GHz) 1
JD724C Cable and Antenna Analyzer (5 MHz to 4 GHz) 1
Options
NOTE: Upgrade options for the JD720C are designated by JD720CU before the respective last three digits
of the option number.
Product Number
Description
JD720C001 RF Power Meter 2
JD720C002 Optical Power Meter 3
Standard accessories
JD72050541
JD720C Soft Carrying Case 4
GC72450522 JD720 AC-DC Adapter 4
G710550335 Cross LAN Cable (1.5 m) 4
GC72450536 USB A to Mini B Cable (1.8 m) 4
GC72450518 > 1 GByte USB Memory 4
GC72450523 JD720 Automotive Cigarette Lighter/12 VDC Adapter 4
G710550325 Rechargeable Lithium Ion Battery 4
G710550316 Stylus Pen 4
JD72050561 JD720C User’s Manual and Application Software CD
1 Requires a calibration kit
2 Requires an RF power sensor
3 Requires an optical power sensor
4 Standard accessories can be purchased separately.
Optional calibration kits
JD72450509 Y - Calibration Kit, Type-N(m), DC to 4 GHz, 50 Ω
JD72450510 Y - Calibration Kit, DIN(m), DC to 4 GHz, 50 Ω
Optional RF cables
G710050530 1.0 m (3.28 ft) RF Cable, DC to 18 GHz, Type-N(m) to Type-N(m), 50 Ω
G710050531 1.5 m (4.92 ft) RF Cable, DC to 18 GHz, Type-N(m) to Type-N(f), 50 Ω
G710050532 3.0 m (9.84 ft) RF Cable, DC to 18 GHz, Type-N(m) to Type-N(f), 50 Ω
Optional RF power sensors
JD731B Directional Power Sensor, 300 MHz to 3.8 GHz, Average 0.15 to 150 W,
Peak 4 to 400 W
JD733A Directional Power Sensor, 150 MHz to 3.5 GHz, Average/Peak
0.1 to 50 W
JD732A Terminating Average Power Sensor, 20 MHz to 3.8 GHz,
–30 to +20 dBm
JD734A Terminating Peak Power Sensor, 20 MHz to 3.8 GHz,
–30 to +20 dBm
JD736A Terminating Average and Peak Power Sensor, 20 MHz to 3.8 GHz,
–30 to +20 dBm
JD72450551 Terminating Average Power Sensor, 40 MHz to 3 GHz,
–30 to 0 dBm
JD72450552 Terminating Peak Power Sensor, 40 MHz to 4 GHz, –40 to 0 dBm
Optional adapters
G710050571 Adapter Type-N(m) to DIN(f), DC to 4 GHz, 50 Ω
G710050572 Adapter DIN(m) to DIN(m), DC to 4 GHz, 50 Ω
G710050573 Adapter Type-N(m) to SMA(f), DC to 18 GHz, 50 Ω
G710050574 Adapter Type-N(m) to BNC(f), DC to 1.5 GHz, 50 Ω
G710050575 Adapter Type-N(f) to Type-N(f), DC to 4 GHz, 50 Ω
G710050576 Adapter Type-N(m) to DIN(m), DC to 4 GHz, 50 Ω
G710050577 Adapter Type-N(f) to DIN(f), DC to 4 GHz, 50 Ω
G710050578 Adapter Type-N(f) to DIN(m), DC to 4 GHz, 50 Ω
G710050579 Adapter DIN(f) to DIN(f), DC to 4 GHz, 50 Ω
Optional optical power sensors
MP-60 Miniature USB 2.0 Optical Power Sensor, +10 dBm
MP-80 Miniature USB 2.0 Optical Power Sensor, +23 dBm
Optional accessories
G710050581 Attenuator 40 dB, 100 W, DC to 4 GHz (Unidirectional)
JD72350542 JD720 Hard Carrying Case
JD720C362 JD720C User’s Manual – Printed Version
