10
JD72OC-SerieS Cable anD antenna analyzerS
General information Supplemental Information
Reflection/RF out
Connector Type-N(f)
Impedance 50 Ω Nominal
Damage level > +40 dBm, > ±50 VDC Nominal
Connectivity
USB Type A, 2 ports For flash drive or power sensor
Mini B, 1 port For JDViewer connection
LAN RJ45, 10/100Base-T For JDViewer connection
Serial 9-pin D-SUB male For JD72450551/50552
Display
Type Resistive touch screen
Size 7-inch transflective
Resolution 800 x 480
Speaker
Built-in speaker
Power
External DC input 12 to 15 VDC
Power consumption 12 W
37.5 W maximum when battery charging
External AC power adapter
Input 100 to 250 V
50 to 60 Hz, 1.2 A
Output 15 VDC, 3 A
Battery
Type 10.8 V, 7200 mA/hr Lithium ion
Operation time >7.5 hours Typical
Storage temperature –10 to 60°C, 20 to 85% RH Store battery pack in a low-humidity environment.
(–14 to 140°F, 20 to 85% RH) Extended exposure to temperatures above
45°C can degrade battery performance and life.
Data storage
Internal Minimum 120 MB
External Limited by size of USB flash drive
Environmental
Operating temperature –10 to 55°C (14 to 131°F)
Humidity 95% With no condensation
Shock and vibration MIL-PRF-28800F Class 2
Storage temperature: –40 to 80°C (–40 to 176°F)
EMC
EN 61326-2-1 Complies with European EMC
Weight and size (with battery)
Weight (with battery) < 2.35 kg (5.18 lb)
Size (W x H x D) 260 x 190 x 60 mm (10.2 x 7.5 x 2.4 in) Approximate
Warranty
2 years
Calibration cycle
2 years
Specifications continued
