JD72OC-SerieS Cable anD antenna analyzerS
Specifications
Frequency Supplemental Information
Range
JD723C
100 MHz to 2.7 GHz
JD724C 5 MHz to 4 GHz
Resolution 10 kHz
Accuracy < ±25 ppm @ 25°C
Data points
126, 251, 501, 1001, 2001
Measurement speed
Reflection < 0.7 ms/point
DTF < 0.8 ms/point
Measurement accuracy
Corrected directivity 40 dB Typical
Reflection uncertainty ±(0.3 + |20log (1 + 10 -EP/20 )|) Typical
EP = directivity – measured return loss
Output power
0 dBm Nominal
Interference immunity
On channel +17 dBm Nominal
On frequency +0 dBm Nominal
Measurements
Reflection (VSWR)
VSWR range 1 to 65
Return loss range 0 to –60 dB
Resolution 0.01
DTF
Vertical VSWR range 1 to 65
Vertical return loss range 0 to –60 dB
Vertical resolution 0.01
Horizontal range 0 to (# of data point – 1) Maximum = 1500 m (4921 ft)
x Horizontal resolution
Horizontal resolution (1.5 x 10 8 ) x (V
p
)/(Delta) V
p
= Propagation velocity
Delta = Stop – Start freq (Hz)
Cable loss (1 Port)
Range 0 to –30 dB
Resolution 0.01 dB
1-Port phase
Range –180 to +180°
Smith chart
Resolution 0.01
Cable and antenna analyzer specifications
apply under these conditions:
• Cable and antenna measurements apply
after calibration to OSL standards.
• The instrument is operating within a
valid calibration period.
• Data without tolerance are considered
typical values.
• Typical or nominal values are defined as:
– Typical: Expected instrument per-
formance operating under 20 to 30°C
when remaining at this temperature
for 15 minutes.
– Nominal: A general, descriptive term
or parameter.
All specifications subject to change without
notice.
