7
Maximum Leveled Output Power With Option 15 (High Power) Installed***:
Minimum Leveled Output Power
Without an Attenuator: –5 dBm (–10 dBm typical)
With an Attenuator: –105 dBm (MG3691B, MG3692B, MG3693B, and MG3694B)
–95 dBm (MG3695B, and MG3696B)
With an Electronic Attenuator: –115 dBm (MG3691B)
Unleveled Output Power Range (typical)
Without an Attenuator: >40 dB below max power.
With an Attenuator: >130 dB below max power.
Power Level Switching Time (to within specified accuracy)
Without Change in Step Attenuator: <3 ms typical
With Change in Step Attenuator: <20 ms typical
With Change in Electronic Step Attenuator: <3 ms typical. Power level changes
across –70 dB step will result in 20 ms delay.
Step Attenuator (Option 2)
Adds a 10 dB/step attenuator, with 110 dB range on models ≤40 GHz, and 90 dB range
on models >40 GHz. Option 2E adds an electronic version with 120 dB range, only
available on an MG3691B. Option 2E is not available on units with Option 22, coverage
down to 0.1 Hz.
Model Number Configuration
Frequency Range
(GHz)
Output Power
(dBm)
Output Power
With Step
Attenuator (dBm)
Output Power
With Electronic
Step Attenuator (dBm)
MG3691B
w/opt 4 or 5
w/opt 4 or 5
w/o opt 4 or 5
< 2* GHz
≥ 2** to ≤10 GHz
≥ 2 to ≤10 GHz
+19.0
+23.0
+25.0
+18.0
+21.0
+23.0
+15.0
+16.0
+16.0
MG3692B
w/opt 4 or 5
w/opt 4 or 5
w/o opt 4 or 5
< 2* GHz
≥ 2** to ≤20 GHz
≥ 2 to ≤20 GHz
+19.0
+21.0
+23.0
+18.0
+19.0
+21.0
Not Available
MG3693B
w/opt 4 or 5
w/opt 4 or 5
w/opt 4 or 5
w/o opt 4 or 5
w/o opt 4 or 5
< 2* GHz
≥ 2** to ≤20 GHz
>20 to ≤30 GHz
≥ 2 to ≤20 GHz
>20 to ≤30 GHz
+17.0
+21.0
+17.0
+23.0
+19.0
+16.0
+19.0
+15.0
+21.0
+17.0
Not Available
MG3694B
w/opt 4 or 5
w/opt 4 or 5
w/opt 4 or 5
w/o opt 4 or 5
w/o opt 4 or 5
< 2* GHz
≥ 2** to ≤20 GHz
>20 to ≤40 GHz
≥ 2 to ≤20 GHz
>20 to ≤40 GHz
+17.0
+21.0
+17.0
+23.0
+19.0
+16.0
+19.0
+15.0
+21.0
+17.0
Not Available
MG3695B
w/opt 4 or 5
w/opt 4 or 5
w/opt 4 or 5
w/opt 4 or 5
w/o opt 4 or 5
w/o opt 4 or 5
w/o opt 4 or 5
< 2* GHz
≥2** to ≤20 GHz
>20 to ≤40 GHz
>40 to ≤50 GHz
≥2 to ≤20 GHz
>20 to ≤40 GHz
>40 to ≤50 GHz
+16
+21
+17
+11
+23
+19
+13
+14
+19
+15
+8
+21
+17
+10
Not Available
MG3696B
w/opt 4 or 5
w/opt 4 or 5
w/opt 4 or 5
w/opt 4 or 5
w/opt 4 or 5
w/o opt 4 or 5
w/o opt 4 or 5
w/o opt 4 or 5
w/o opt 4 or 5
< 2* GHz
≥2** to ≤20 GHz
>20 to ≤40 GHz
>40 to ≤67 GHz
>67 to ≤70 GHz
≥2 to ≤20 GHz
>20 to ≤40 GHz
>40 to ≤67 GHz
>67 to ≤70 GHz
+16
+19
+16
+9
+3*****
+21
+19
+9
+3*****
+15
+18
+14
+6****
0*****
+19
+16
+6****
0*****
Not Available
* ≤2.2 GHz with Option 4
** >2.2 GHz with Option 4
*** For output power with Option 22, 0.1 Hz to 10 MHz coverage, derate all specifications by 2 dB
**** Typical 60 to 67 GHz
***** Typical
* ≤2.2 GHz with Option 4
** >2.2 GHz with Option 4
