16
Millimeter Wave Accessories (Option 18 recommended for DC bias)
63850-15
50-75 GHz V band Multiplier Source Module, WR-15
63850-12 60-90 GHz E band Multiplier Source Module, WR-12
63850-10 75-110 GHz W band Multiplier Source Module, WR-10
63850-08 90-140 GHz F band Multiplier Source Module, WR-08
63850-06 110-170 GHz D band Multiplier Source Module, WR-06
63850-05 140-220 GHz G band Multiplier Source Module, WR-05
63850-03 220-325 GHz H band Multiplier Source Module, WR-03
806-121 SMA male-male flexible cable, 90 cm (3 ft) (could be used to connect the MG3690B output to the module's LO input)
Accessories
34RKNF50
DC to 20 GHz, Ruggedized Type N female adapter for units with a K connector output
ND36329 MASTER/SLAVE interface cable set
63270 Transit case (16 kg, 66 cm x 41 cm x 81 cm, roll-away on four wheels)
2300-469 IVI Driver, includes LabView® driver
806-97
Aux I/O Cable, 25 pin to BNC: Provides BNC access to Aux I/O Data Lines: Sequential Sync, Marker Out, Bandswitch Blanking,
Retrace Blanking, Sweep Dwell In, V/GHz, Horizontal Out.
Upgrades
Economical upgrades are available to upgrade any model to any higher performing model. Consult Anritsu for details.
