Ordering Information
* Pulse Modulation performance is controlled by United States Export Control regulations, >31.8 GHz. For Pulse Modulation solutions that do not require export licenses, please consult with your
Anritsu sales representative.
Models
MG3691B
2 – 10 GHz Signal Generator
MG3692B 2 – 20 GHz Signal Generator
MG3693B 2 – 30 GHz Signal Generator
MG3694B 2 – 40 GHz Signal Generator
MG3695B 2 – 50 GHz Signal Generator
MG3696B 2 – 67 GHz Signal Generator (operational to 70 GHz)
Options and Accessories
MG3690B/1A
Rack Mount with slides – Rack mount kit containing a set of track slides (90 degree tilt capability), mounting ears, and front panel handles to let the
instrument be mounted in a standard 19-inch equipment rack.
MG3690B/1B
Rack Mount without slides – Modifies rack mounting hardware to install unit in a console that has mounting shelves. Includes mounting ears and
front panel handles.
MG3690B/2X
Mechanical Step Attenuator – Adds a 10 dB/step attenuator. Rated RF output power is reduced. (This option comes in different versions, based
on instrument configuration.)
MG3690B/2E
Electronic Step Attenuator – Adds a 10 dB/step electronic attenuator with a 120 dB range for the MG3691B. Rated RF output power is reduced.
(Not available with Option 20 or 22.)
MG3690B/3 Ultra Low Phase Noise, main band – Adds new modules to significantly reduce SSB phase noise.
MG3690B/4 10 MHz to 2.2 GHz RF coverage, Ultra-Low Phase Noise version – Uses a digital down converter to significantly reduce SSB phase noise.
MG3690B/5 10 MHz to 2 GHz RF coverage – Uses an analog down converter.
MG3690B/6 Analog Sweep Capability – (limited to ≥500 MHz when used with Option 4.)
MG3690B/7 IF Up-Conversion – Adds an internal 40 GHz mixer for up-converting an IF signal. (Not available with MG3695B, MG3696B, or with Options 18 or 20.)
MG3690B/8 Power Monitor – Adds internal power measurement capability. (Not available with Option 9.)
MG3690B/9X
Rear Panel Output – Moves the RF output connector to the rear panel. (This option comes in different versions, based on instrument configuration.)
(Not available with Option 8.)
MG3690B/10
User-Defined Modulation Waveform Software – External software package provides the ability to download user-defined waveforms into the memory
of the internal waveform generator, serially or via GPIB. External PC and an instrument with LF Generator, Option 27, are required.
MG3690B/12
Frequency and Phase Modulation – External, via a rear panel BNC connector. For internal modulation capability, requires additionally LF Generator,
Option 27.
MG3690B/14 Amplitude Modulation – External, via a rear panel BNC connector. For internal modulation capability, requires additionally LF Generator, Option 27.
MG3690B/15X
High Power – Adds high-power RF components to the instrument to increase its output power level.
(This option comes in different versions, based on instrument configuration, not available on MG3696B)
MG3690B/16 High Stability Time Base – Adds an ovenized, 10 MHz crystal oscillator as a high-stability time base.
MG3690B/17
Delete Front Panel – Deletes the front panel for use in remote control applications where a front panel display and keyboard control are not needed.
(Only available with Options 1A or 1B)
MG3690B/18
mmW Bias Output – Adds a rear panel BNC Twinax connector required to bias the 63850 series millimeter wave source modules, sold separately.
Includes DC bias cable. (Not available with Option 7 or 15x)
MG3690B/20
Scan Modulation – Adds an internal Scan modulator for simulating high-depth amplitude modulated signals. Requires an external modulating signal input
capability. (Not available on models MG3693B, MG3694B, MG3695B, MG3696B, or with Options 2E, 7, 15X, or 22.)
MG3690B/22
0.1 Hz to 10 MHz Audio coverage – Uses a DDS for coverage down to approximately DC. When adding Option 22, the output power is derated by 2 dB.
The frequency resolution below 10 MHz is 0.02 Hz. No modulation is available in the 0.1 Hz to 10 MHz band. (Not available without Option 4 or 5,
or with Option 20 or 2E)
MG3690B/26X*
Pulse Modulation – External, via a rear panel BNC connector. For internal modulation capability, requires additionally Pulse Generator, Option 27.
(This option comes in different versions, based on instrument configuration.)
MG3690B/27
Internal LF and Pulse Generators – Provides modulation waveforms for internal AM, FM, ΦM, and Pulse.
(Not available without Option 12, 14, or 26.)
MG3690B/28X*
Analog Modulation Suite – For ease of ordering and package pricing, this option bundles Options 12, 14, 26 and 27, offering internal and external AM, FM, ΦM,
and Pulse Modulation. (This option comes in different versions , based on instrument configuration.)
MG3690B/30 Low Phase Noise
