Specifications
(at 0 ° to 55 °C unless otherwise specified)
6654A-J04
Special order
option
6654A-J05
Special order
option
6654A-J12
Special order
option
6655A-J05
Special order
option
Special order
option
Number of outputs
1 1
1 1 1
GPIB
Yes Yes Yes Yes Yes
Output ratings
Output voltage
70 V
50 V
80 V
150 V
156 V
Output current (40 °C)
7.5 V
10 A
6 A
3.2 A
3 A
Maximum current (50 °C/55 °C)
6.75 A/6.37 A
9 A/8.5 A
5.4 A/5.1 A
2.88 A/2.72 A
2.7 A/2.55 A
Programming accuracy (at 25 °C ± 5 °C)
Voltage 0.06%
+
30 mV
26 mV
35 mV
64 mV
71 mV
Current 0.15%
+
7 mA
9 mA
7 mA
3.5 mA
4 mA
Ripple and noise from 20 Hz to 20 MHz
Voltage rms
600 μV
500 μV
700 μV
800 μV
900 μV
peak-to-peak 6 mV
5 mV
7 mV
8 mV
8 mV
Current rms
5 mA
4 mA
3 mA
2 mA
3 mA
Readback accuracy at 25 °C ± 5 °C
(percent of reading plus fi xed)
Voltage 0.07%
+
50 mV
40 mV
58 mV
100 mV
110 mV
+Current
0.15% +
6 mA
8 mA
6 mA
2.5 mA
3 mA
–Current 0.35%
+
13 mA
17 mA
16 mA
6.5 mA
7.5 mA
Load regulation
Voltage
4 mV
4 mV
4 mV
6 mV
7 mV
Current
0.5 mA
0.5 mA
0.5 mA
0.5 mA
1 mA
Line regulation
Voltage
1 mV
1 mV
4.5 mV
2 mV
2 mV
Current
0.5 mA
0.5 mA
0.5 mA
0.5 mA
1 mA
Transient response time
Less than 100 μs for the output voltage to recover to its previous level (within 0.1%
of the voltage rating of the supply or 20 mV, whichever is greater) following any step
change in load current of up to 50% of rated current
Supplemental characteristics
(Non-warranted characteristics determined
by design and useful in applying the product)
6654A-J04
Special order
option
6654A-J05
Special order
option
6654A-J12
Special order
option
6655A-J05
Special order
option
6655A-J10
Special order
option
Average programming resolution
Voltage
17.5 mV
15 mV
20 mV
37.5 mV
39.5 mV
Current
1.9 mA
2.75 mA
1.7 mA
8 mA
8 mA
OVP
110 mV
93 mV
130 mV
240 mV
250 mV
OVP accuracy
1.4 V
1.2 V
1.6 V
3 V
3.3 V
