Specifi cations
Specifications
(at 0 ° to 55 °C unless otherwise
specified)
6651A
6652A
6653A
6654A
6655A
6651A-J05
Special order
option
Number of outputs
1 1 1 1 1
1
GPIB
Yes Yes Yes Yes Yes
Yes
Output ratings
Output voltage
0 to 8 V
0 to 20 V
0 to 35 V
0 to 60 V
0 to 120 V
10 V
Output current (40 °C)
0 to 50 A
0 to 25 A
0 to 15 A
0 to 9 A
0 to 4 A
50 A
Maximum current (50 °C/55 °C)
45 A/42.5 A
22.5 A/21.3 A 13.5 A/12.8 A 8.1 A/7.7 A
3.6 A/3.4 A
45 A/42.5 A
Programming accuracy (at 25 °C ± 5 °C)
Voltage
0.06% +
5 mV
10 mV
15 mV
26 mV
51 mV
6 mV
Current
0.15% +
60 mA
25 mA
13 mA
8 mA
4 mA
60 mA
Ripple and noise from 20 Hz to 20 MHz
Voltage
rms
300 μV
300 μV
400 μV
500 μV
700 μV
300 μV
peak-to-peak
3 mV
3 mV
4 mV
5 mV
7 mV
3 mV
Current
rms
25 mA
10 mA
5 mA
3 mA
2 mA
25 mA
Readback accuracy at 25 °C ± 5 °C
(percent of reading plus fi xed)
Voltage
0.07% +
6 mV
15 mV
25 mV
40 mV
80 mV
7.5 mV
+Current
0.15% +
67 mA
26 mA
15 mA
7 mA
3 mA
67 mA
–Current
0.35% +
100 mA
44 mA
24 mA
15 mA
7 mA
100 mA
Load regulation
Voltage
1 mV
2 mV
3 mV
4 mV
5 mV
1 mV
Current
2 mA
1 mA
0.5 mA
0.5 mA
0.5 mA
2 mA
Line regulation
Voltage
0.5 mV
0.5 mV
1 mV
1 mV
2 mV
0.5 mV
Current
2 mA
1 mA
0.75 mA
0.5 mA
0.5 mA
2 mA
Transient response time
Less than 100 μs for the output voltage to recover to its previous level (within 0.1% of the
voltage rating of the supply or 20 mV, whichever is greater) following any step change in
load current of up to 50% of the output current rating of the supply
Supplemental characteristics
(Non-warranted characteristics
determined by design and useful in
applying the product)
6651A
6652A
6653A
6654A
6655A
6651A-J05
Special order
option
Average programming resolution
Voltage
2 mV
5 mV
10 mV
15 mV
30 mV
2.5 mV
Current
15 mA
7 mA
4 mA
2.5 mA
1.25 mA
15 mA
OVP
12 mV
30 mV
54 mV
93 mV
190 mV
16 mV
OVP accuracy
160 mV
400 mV
700 mV
1.2 V
2.4 V
200 mV
