4
Specifi cations, continued
Specifications
(at 0 ° to 55 °C unless otherwise
specified) 6575A-J04
Special order
option
6575A-J06
Special order
option
6575A-J07
Special order
option
6575A-J08
Special order
option
6575A-J09
Special order
option
6575A-J11
Special order
option
Number of outputs 1 1 1 1 1 1
GPIB No No No No No No
Output ratings
Output voltage 160 V 135 V 200 V 100 V 110 V 150 V
Output current 13 A 16 A 11 A 22 A 20 A 15 A
Programming accuracy (at 25 °C ± 5 °C)
Voltage 0.04% + 160 mV 125 mV 200 mV 120 mV 120 mV 150 mV
Current 0.1% + 10 mA 12 mA 8 mA 15 mA 13.5 mA 11 mA
Ripple and noise from 20 Hz to 20 MHz
Voltage rms 2.8 mV 2 mV 3.5 mV 1.9 mV 1.9 mV 2.5 mV
peak-to-peak 20 mV 18 mV 25 mV 16 mV 16 mV 18 mV
Current rms 18 mA 12 mA 15 mA 15 mA 13.5 mA 12 mA
Load and line regulation
Voltage 0.002% + 6 mA 4 mA 7 mA 4 mV 4 mV 6 mV
Current 0.005% + 1 mA 4 mA 1 mA 4 mA 4 mA 1 mA
Transient response time Less than 900 μs for the output voltage to recover to within 100 mV following a change in
load from 100% to 50% or 50% to 100% of the output current rating of the supply
Supplemental characteristics
(Non-warranted characteristics
determined by design and useful in
applying the product)
6575A-J04
Special order
option
6575A-J06
Special order
option
6575A-J07
Special order
option
6575A-J08
Special order
option
6575A-J09
Special order
option
6575A-J11
Special order
option
Average programming resolution
Voltage 40 mV 34 mV 50 mV 30 mV 30 mV 37.5 mV
Current 3.25 mA 4 mA 2.75 mA 4.5 mA 4.5 mA 3.75 mA
OVP 300 mV 242 mV 360 mV 215 mV 215 mV 270 mV
Output voltage programming
response time* (excluding command
processing time) 280 ms 250 ms 350 ms 195 ms 195 ms 250 ms
* Full load programming rise/fall time (10% to 90% or 90% to 10%) with full resistive load equal to rated output voltage/rated output current.
