Specifi cations, continued
Specifications
(at 0 ° to 55 °C unless otherwise
specified) 6571A-J04
Special order
option
6571A-J17
Special order
option
6573A-J03
Special order
option
6573A-J08
Special order
option
6574A-J03
Special order
option
6574A-J07
Special order
option
Number of outputs 1 1 1 1 1 1
GPIB No No No No No No
Output ratings
Output voltage 10 V 15 V 37.5 V 40 V 56 V 50 V
Output current 200 A 120 A 45 A 50 A 38 A 42 A
Programming accuracy (at 25 °C ± 5 °C)
Voltage 0.04% + 10 mV 15 mV 37.5 mV 40 mV 60 mV 60 mV
Current 0.1% + 125 mA 90 mA 40 mA 35 mA 28 mA 30 mA
Ripple and noise from 20 Hz to 20 MHz
Voltage rms 750 μV 1.5 mV 800 μV 1 mV 1.25 mV 1.25 mV
peak-to-peak 9 mV 15 mV 9 mV 10.5 mV 11 mV 11 mV
Current rms 200 mA 150 mA 40 mA 40 mA 28 mA 25 mA
Load and line regulation
Voltage 0.002% + 300 μV 650 μV 1.2 mV 1.4 mV 2 mV 2 mV
Current 0.005% + 10 mA 7 mA 4 mA 4 mA 2 mA 2 mA
Transient response time Less than 900 μs for the output voltage to recover to within 100 mV following a change in
load from 100% to 50% or 50% to 100% of the output current rating of the supply
Supplemental characteristics
(Non-warranted characteristics
determined by design and useful in
applying the product)
6571A-J04
Special order
option
6571A-J17
Special order
option
6573A-J03
Special order
option
6573A-J08
Special order
option
6574A-J03
Special order
option
6574A-J07
Special order
option
Average programming resolution
Voltage 2.5 mV 4 mV 10 mV 10.5 mV 14 mV 12 mV
Current 55 mA 35 mA 15 mA 12.5 mA 9.5 mA 11 mA
OVP 20 mV 30 mV 65 mV 75 mV 100 mV 85 mV
Output voltage programming
response time* (excluding command
processing time) 35 ms 35 ms 130 ms 130 ms 130 ms 130 ms
* Full load programming rise/fall time (10% to 90% or 90% to 10%) with full resistive load equal to rated output voltage/rated output current.
