Specifi cations
Specifications
(at 0 ° to 55 °C unless otherwise specified)
6571A 6572A 6573A 6574A 6575A
6571A-J03
Special order
option
Number of outputs 1 1 1 1 1 1
GPIB No No No No No No
Output ratings
Output voltage 0 to 8 V 0 to 20 V 0 to 35 V 0 to 60 V 0 to 120 V 14 V
Output current 0 to 220 A 0 to 100 A 0 to 60 A 0 to 35 A 0 to 18 A 150 A
Programming accuracy (at 25 °C ± 5 °C)
Voltage 0.04% + 8 mV 20 mV 35 mV 60 mV 120 mV 14 mV
Current 0.1% + 125 mA 60 mA 40 mA 25 mA 12 mA 90 mA
Ripple and noise from 20 Hz to 20 MHz
Voltage rms 650 μV 750 μV 800 μV 1.25 mV 1.9 mV 1.5 mV
peak-to-peak 7 mV 9 mV 9 mV 11 mV 16 mV 15 mV
Current rms 200 mA 100 mA 40 mA 25 mA 12 mA 150 mA
Load and line regulation
Voltage 0.002% + 300 μV 650 μV 1.2 mV 2 mV 4 mV 600 μV
Current 0.005% + 10 mA 7 mA 4 mA 2 mA 1 mA 7 mA
Transient response time Less than 900 μs for the output voltage to recover to within 100 mV following a change
in load from 100% to 50% or 50% to 100% of the output current rating of the supply
Supplemental characteristics
(Non-warranted characteristics determined
by design and useful in applying the product)
6571A 6572A 6573A 6574A 6575A
6571A-J03
Special order
option
Average programming resolution
Voltage 2 mV 5 mV 9 mV 15 mV 30 mV 4 mV
Current 55 mA 25 mA 15 mA 8.75 mA 4.5 mA 40 mV
OVP 15 mV 35 mV 65 mV 100 mV 215 mV 28 mV
Output voltage programming
response time* (excluding command
processing time) 30 ms 60 ms 130 ms 130 ms 195 ms 30 ms
* Full load programming rise/fall time (10% to 90% or 90% to 10%) with full resistive load equal to rated output voltage/rated output current.
