DATA SHEET > NetWave Series 3-phase > 20130606

TECHNICAL DETAILS

OTHER SOLUTIONS

OTHER MODELS

NetWave Series
(1-phase)

Single phase Multifunction AC/DC
Power sources, up to 7,500VA AC
and 9,000W DC

OTHER EQUIPMENT

DPA 503N

3-phase Harmonics and Flicker
analyzer

AIF 503N16

3-phase flicker impedance,
3x400V, 16A
0.24ohm + j0.15ohm (Lines)
0.16ohm + j0.10ohm (Neutral)

AIF 503N32

3-phase dual-impedance,
3x400V, 32A
Zref:
0.24ohm + j0.15ohm (Lines)
0.16ohm + j0.10ohm (Neutral)
Ztest:
0.15ohm + j0.15ohm (Lines)
0.10ohm + j0.10ohm (Neutral)

AIF 503N63

3-phase dual-impedance,
3x400V, 63A
Zref:
0.24ohm + j0.15ohm (Lines)
0.16ohm + j0.10ohm (Neutral)
Ztest:
0.15ohm + j0.15ohm (Lines)
0.10ohm + j0.10ohm (Neutral)

AIF 503N75

3-phase dual-impedance,
3x400V, 75A
Zref:
0.24ohm + j0.15ohm (Lines)
0.16ohm + j0.10ohm (Neutral)
Ztest:
0.15ohm + j0.15ohm (Lines)
0.10ohm + j0.10ohm (Neutral)
