DATA SHEET > NetWave Series 3-phase > 20130606

TECHNICAL DETAILS

MODEL OVERVIEW

3-PHASE NETWAVE-MODELS

NetWave 20.x

3-phase Multifunction AC/DC source,
22,500VA AC / 27,000W DC

NetWave 30.x

3-phase Multifunction AC/DC source,
30,000VA AC / 36,000W DC

NetWave 60.x

3-phase Multifunction AC/DC source,
60,000VA AC / 72,000W DC

TECHNICAL DETAILS

NETWAVE 20

Output voltage

0V - 3*300V AC (p-n)
0V - +/- 425V DC

Output current

26A (RMS) continuous
47A (RMS) short-term (max. 3s)
200A repetitive peak

NETWAVE 20.2

Output voltage

0V - 3*360V AC (p-n)
0V - 3*620V AC (p-p)
0V - +/- 500V DC

Output current (@
max. 300V AC)

26A (RMS) continuous
47A (RMS) short-term (max. 3s)
200A repetitive peak

NETWAVE 30

Output voltage

0V - 3*300V AC (p-n)
0V - +/- 425V DC

Output current

33A (RMS) continuous
66A (RMS) short-term (max. 3s)
250A repetitive peak

NETWAVE 30.2

Output voltage

0V - 3*360V AC (p-n)
0V - 3*620V AC (p-p)
0V - +/- 500V DC

Output current (@
max. 300V AC)

33A (RMS) continuous
66A (RMS) short-term (max. 3s)
250A repetitive peak

TECHNICAL DETAILS

NETWAVE 60

Output voltage

0V - 3*300V AC (p-n)
0V - +/- 425V DC

Output current

66A (RMS) continuous
100A (RMS) short-term (max. 3s)
400A repetitive peak

NETWAVE 60.2

Output voltage

0V - 3*360V AC (p-n)
0V - 3*620V AC (p-p)
0V - +/- 500V DC

Output current (@
max. 300V AC)

66A (RMS) continuous
100A (RMS) short-term (max. 3s)
400A repetitive peak

EXTENDED CAPABILITIES FOR NETWAVE

Simple mode

Optimized control for integration of
the Netwave into existing
automation environments (for
example Matlab)

SourceAC mode

PLL synchronization with other
voltage sources

Trigger channel

Extended trigger functions

Segment "Step"

Ramping of voltage and/or frequency
in constant time windows

Extern mode

Control of the NetWave by an
external control signal

www.emtest.com

© EM TEST > PAGE 2/6
