DATA SHEET > NetWave Series 3-phase > 20130606

TECHNICAL DETAILS

OPTIONS

OPTIONAL SOFTWARE

NW3 License 1

Software license for DO-160
standard for NetWave-series
(3-phase)

NW3 License 2

Software license for MIL-STD-704
standard for NetWave-series
(3-phase)

NW3 License 3

Software license for AIRBUS
standards for NetWave-series
(3-phase)

NW3 License 4

Software license for analysis
functions as min., max., average
and ...,
power and harmonic measurement,
(requires the option "NWBoard")

NW3 License 5

Software license for BOEING
standards for NetWave-series
(3-phase)
Requires Netwave model for 360VAC

NW-BOARD MEASURING MODULE

Channels

Built in 6 channel (3-phase)
measurement board for
3* voltage
3* current

Voltage ranges

25V, 50V, 100V, 250V, 550V,
unipolar or bipolar

Current ranges

10A, 25A, 50A, 100A, 220A,
unipolar or bipolar

Resolution

16 Bit

Accuracy

Voltage: better than 0.2%
Current: better than 0.5%

Frequency range

DC - 100kHz

Sampling rate

5Hz - 200kHz, selectable

Memory

Min. 40GB on hard disk,
File size max. 1GB

OPTIONS

POWER RECOVERY (OPTION POWERRECOVERY 20/30, 60)

Available for all 3-phase NetWave
models

Mains voltage

400V +/- 10% (45Hz - 65Hz)

Recoverable
power

up to nominal AC/DC power of the
individual NetWave model

NetWave 20.x

Max. 22.5kVA AC / 27kW DC
26A (RMS) continuous
47A (RMS) short max. 3s
200A repetitive peak

NetWave 30.x

Max. 30kVA AC / 36kW DC
33A (RMS) continuous
66A (RMS) short max. 3s
250A repetitive peak

NetWave 60.x

Max. 60kVA AC / 72kW DC
66A (RMS) continuous
100A (RMS) short max. 3s
400A repetitive peak

Power factor

> 0.92 (cos phi) at full load

PARALLEL MODE HARDWARE (OPTION PARALLELMODE
20/30, 60)

Parallel Mode

The parallel mode will connect all
three internal sources together in
parallel.
The common 1-phase output is on a
separate terminal block for EUT
connection.
During parallel mode the 3-phase
terminals are disconnected from the
source.

NetWave 20.x

78A (RMS) continuous
141A (RMS) short max. 3s
600A repetitive peak

NetWave 30.x

99A (RMS) continuous
198A (RMS) short max. 3s
750A repetitive peak

NetWave 60.x

198A (RMS) continuous
300A (RMS) short max. 3s
1200A repetitive peak
