BTS Master™ MT8221B, MT8222B Ordering Information
Power Sensors (For complete ordering information see the respective datasheets of each sensor)
Part Number Description
PSN50 High Accuracy RF Power Sensor, 50 MHz to 6 GHz, +20 dBm
MA24104A Inline High Power Sensor, 600 MHz to 4 GHz, + 51.76 dBm
MA24106A High Accuracy RF Power Sensor, 50 MHz to 6 GHz, +23 dBm
MA24108A Microwave USB Power Sensor, 10 MHz to 8 GHz, +20 dBm
MA24118A Microwave USB Power Sensor, 10 MHz to 18 GHz, +20 dBm
MA24126A Microwave USB Power Sensor, 10 MHz to 26 GHz, +20 dBm
Manuals (soft copy included on Handheld Instruments Documentation Disc and at www.anritsu.com)
Part Number Description
10920-00060 Handheld Instruments Documentation Disc
10580-00207 BTS Master User Guide (Hard copy included)
- Bias-Tee, GPS Receiver
10580-00230 Cable and Antenna Analyzer Measurement Guide
10580-00244 Spectrum Analyzer Measurement Guide
- Interference Analyzer, Channel Scanner, IF Output, Gated Sweep
10580-00240 Power Meter Measurement Guide
- High Accuracy Power Meter
10580-00232 Vector Signal Generator Measurement Guide
10580-00234 3GPP Signal Analyzer Measurement Guide
- GSM/EDGE, W-CDMA/HSDPA, TD-SCDMA/HSDPA, LTE
10580-00235 3GPP2 Signal Analyzer Measurement Guide
- CDMA, EV-DO
10580-00236 WiMAX Signal Analyzer Measurement Guide
- Fixed WiMAX, Mobile WiMAX
10580-00238 Backhaul Analyzer Measurement Guide
- T1, E1, T1/T3
10580-00208 Programming Manual
10580-00209 Maintenance Manual
Troubleshooting Guides (soft copy at www.anritsu.com)
Part Number Description
11410-00473 Cable, Antenna and Components
11410-00551 Spectrum Analyzers
11410-00472 Interference
11410-00566 LTE eNodeB Base Stations
11410-00466 GSM/GPRS/EDGE Base Stations
11410-00463 W-CDMA/HSDPA Base Stations
11410-00465 TD-SCDMA/HSDPA Base Stations
11410-00467 cdmaOne/CDMA2000 1X Base Stations
11410-00468 CDMA2000 1xEV-DO Base Stations
11410-00470 Fixed WiMAX Base Stations
11410-00469 Mobile WiMAX Base Stations
11410-00552 T1/DS1 Backhaul Testing
11410-00553 E1 Backhaul Testing
Standard Accessories (included with instrument)
Part Number Description
10920-00060 Handheld Instruments Documentation Disc
10580-00207 BTS Master User Guide (includes Bias-Tee and GPS Receiver)
65681 Soft Carrying Case
2300-498 Master Software Tools (MST) CD Disc
2300-530 Anritsu Tool Box with Line Sweep Tools (LST) DVD Disc
633-44 Rechargeable Li-Ion Battery
40-168-R AC/DC Power Supply
806-141-R Automotive Cigarette Lighter 12 Volt DC Adapter
3-806-152 Cat 5e Crossover Patch Cable, 7 feet/213 cm
2000-1371-R Ethernet Cable, 7 feet/213 cm
3-2000-1498 USB A-mini B Cable, 10 feet/305 cm
1091-27-R Type-N male to SMA female adapter
1091-172-R Type-N male to BNC female adapter
11410-00442 BTS Master MT822xB Technical Data Sheet
One Year Warranty (Including battery, firmware, and software)
Certificate of Calibration and Conformance
