Ordering Information BTS Master™ MT8220T
Directional Antennas
Portable Antennas
Mag Mount Broadband Antenna
Part Number Description
2000-1411-R 824 MHz to 896 MHz, N(f), 10 dBd, Yagi
2000-1412-R 885 MHz to 975 MHz, N(f), 10 dBd, Yagi
2000-1413-R 1710 MHz to 1880 MHz, N(f), 10 dBd. Yagi
2000-1414-R 1850 MHz to 1990 MHz, N(f), 9.3 dBd, Yagi
2000-1415-R 2400 MHz to 2500 MHz, N(f), 10 dBd, Yagi
2000-1416-R 1920 MHz to 2170 MHz, N(f), 10 dBd, Yagi
2000-1659-R 698 MHz to 787 MHz, N(f), 8 dBd, Yagi
2000-1660-R 1425 MHz to 1535 MHz, N(f), 12.2 dBd, Yagi
2000-1677-R 300 MHz to 3000 MHz, SMA(m), 50 Ω, 3 m cable (9.8 ft),
0 to 6 dBi gain @ 950 MHz, log periodic
2000-1617 600 MHz to 21 GHz, N(f), 5 to 8 dBi to 12 GHz,
0 to 6 dBi to 21 GHz, log periodic
2000-1726-R Antenna, Yagi 2500 MHz to 2700 MHz N(f), 12 dBd
2000-1747-R Antenna, Log Periodic, 300 MHz to 5000 MHz N(f), 5.1 dBi,
typical
2000-1748-R Antenna, Log Periodic, 1 GHz to 18 GHz, N(f), 6 dBi, typical
Part Number Description
2000-1200-R 806 MHz to 866 MHz, SMA(m), 50 Ω
2000-1473-R 870 MHz to 960 MHz, SMA(m), 50 Ω
2000-1035-R 896 MHz to 941 MHz, SMA(m), 50 Ω (1/2 wave)
2000-1030-R 1710 MHz to 1880 MHz, SMA(m), 50 Ω (1/2 wave)
2000-1474-R 1710 MHz to 1880 MHz with knuckle elbow (1/2 wave)
2000-1031-R 1850 MHz to 1990 MHz, SMA(m), 50 Ω (1/2 wave)
2000-1475-R 1920 MHz to 1980 MHz and 2110 to 2170 MHz, SMA(m), 50 Ω
2000-1032-R 2400 MHz to 2500 MHz, SMA(m), 50 Ω (1/2 wave)
2000-1361-R 2400 MHz to 2500, 5000 MHz to 6000 MHz, SMA(m), 50 Ω
2000-1677-R 300 MHz to 3000 MHz, SMA(m), 50 Ω, 3 m cable (9.8 ft),
0 to 6 dBi gain @ 950 MHz, log periodic
2000-1636-R Antenna Kit (Consists of: 2000-1030-R, 2000-1031-R,
2000-1032-R, 2000-1200-R, 2000-1035-R, 2000-1361-R, and
carrying pouch)
2000-1751-R LTE Dipole, 698-960/1710-2170/2500-2700 MHz, SMA(m), 2 dBi,
typical, 50 Ω
Part Number Description
2000-1647-R Cable 1: 698 MHz to 1200 MHz 2 dBi peak gain,
1700 MHz to 2700 MHz 5 dBi peak gain, N(m), 50 Ω, 3 m (9.8 ft)
Cable 2: 3000 MHz to 6000 MHz 5 dBi peak gain, N(m), 50 Ω,
3 m (9.8 ft)
Cable 3: GPS 26 dB gain, SMA(m), 50 Ω, 3 m (9.8 ft)
2000-1645-R 694 MHz to 894 MHz 3 dBi peak gain,
1700 MHz to 2700 MHz 3dBi peak gain, N(m), 50 Ω, 3 m (9.8 ft)
2000-1646-R 750 MHz to 1250 MHz 3 dBi peak gain,
1650 MHz to 2000 MHz 5 dBi peak gain,
2100 MHz to 2700 MHz 3 dBi peak gain, N(m), 50 Ω, 3 m (9.8 ft)
2000-1648-R 1700 MHz to 6000 MHz 3 dBi peak gain,N(m), 50 Ω, 3 m (9.8 ft)
